Integrated Clock Chip Conguration
► ICC Enable
This item is used to enable or disable the Integrated Clock Chip.
► ICC Set Clock Enables
This item is used to enable or disable the ICC Set Clock Enabled.
► Set ICC Lock Registers
This item is used to enable or disable the function of sending ICC Lock Registers message.
► Set Prole
This item is used to enable or disable the ICC prole support.
► Set Prole Index
This item is used to set the prole index. it only have one ICC Prole, so it always showed 0
when ICC set prole enable.
► ICC OverClocking
This item is used to display or set ICC clock spread spectrum. You could press <Enter> to go
to its submenu. The submenu include the following option: [DIV-1S], [DIV-2S], [DIV3], [DIV4],
[DIV-1NS], [DIV-2NS].
[DIV-1S]:
Clock 1 spread spectrum setting. But this clock is not used. Only display the default setting
and user can’t change the setting.
[DIV-2S]:
Clock 2 spread spectrum setting. And the clock is used to set spectrum for BCLK, DMI and
PEG.
[DIV3]:
Clock 3 spread spectrum setting. And the clock is used to set spectrum for PCIe, PCI33, SATA
and USB3.
[DIV4]:
Clock 1 spread spectrum setting. But this clock is not used. Only display the default setting
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Integrated Clock Chip Configuration
ICC OverClocking Lib Version 7.0.0.29
Number of ICC Profiles : 1
Current ICC Profile Index : 0
ICC Enable [Enabled]
ICC Set Clock Enables [Enabled]
Send ICC Lock Registers [Enabled]
Set
Profile [Enabled]
Set Profile Index 0
▶ ICC OverClocking
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4:
Save & Exit
ESC: Exit
Integrated Clock Chip
Enabled/Disabled.
Chipset
