This manual is suitable for motherboard of P9657AA. Each
motherboard is carefully designed for the PC user who wants
diverse features.
-L with onboard 10/100M LAN (Default is omitted.)
-K with onboard Gigabit LAN
-6 with 6-Channel audio (Default is omitted.)
-8 with 8-Channel audio
-E with 1394 function
-S with SATA function
-2 with DDR2 function
-Rwith RAID function
-H comply with RoHS directives
You can find PPID label on the motherboard. It indicates the
functions that the motherboard has.
For example:
The letters on the black mark of the PPID label, it means the
motherboard supports 6-Channel Audio (-6)(default), 1394
port (-E), onboard 10/100M LAN (-L)(default), SATA function (-
S).
