FoxESS A7300P1-E1-R - Technical Data

5
5. Technical Data
Model
A7300
General
Name
AC Charger
Input
Input line
1P+N+PE
Rated voltage
230Vac，±20%
Rated current
32A
Rated frequency
50/60Hz
Output
Output voltage
230Vac，±20%
Maximum output current
32A
Rated power
7.3kW
Interaction method
Charging connection method
With cable/socket
Card reader
Mifare ISO/IEC 14443 A
Start-up mode
Plug and Charge/RFID Card/APP
Communication method
Bluetooth
Yes，3db，-40-85℃
WiFi
Yes
，
2412-2484MHz,802.11b/g/n
：
20db
Using environment
Installation method
Wall mounting/column mounting
Working temperature
-30°C~50°C
Working humidity
5%-95% no condensation
Altitude
≤2000m
Size and weight
Size
320*190*144.5 mm(socket),320*190*130 mm(plug)
Weight
2.0kg(socket),3.55kg(plug)
Safety
Waterproof rating
IP65
Anti-collision grade
IK08
Type A RCD
6mA DC
Protection function
Over-current protection, grounding protection,
lightning protection, over-voltage protection,
under-frequency protection, over-under-temperature
protection
Certification
CE/UKCA
Certification standard
EN/IEC 61851-1: 2019, EN/IEC 61851-21-2: 2018
