5. Product Information
1. HV2600 is a battery module, it needs to be used with BMS BOX controller;
2. BMS BOX is the controller of the whole system, so each system must have one BMS BOX;
3. Our system consists of at least 2 HV2600 + 1 BMS BOX and up to 8 HV2600 + 1 BMS BOX.
5.1 Battery Module Specifications
5.2 BMS Specifications
Specifications for HV2600
Battery module
HV2600
Nominal capacity (kWh)
2.6
Maximum charge voltage (V)
58.4
Discharge cut voltage (V)
40
Max. charge/discharge current (A)
50A/50A
Operating temperature (°C)
-10 ~ 50
Storage temperature (°C)
-20 ~50
Charge/Discharge efficiency (%)
>98
Ingress protection
IP21
Protective class
I
Cycle life
>6000 @25°C @90% DOD
Available SOC range
10%~100%
Weight (kg)
29.7±1 kg
Dimensions (L*W*H) (mm)
420*480*116
Specifications for BMS BOX
Model NO.
BMS-BOX
Operating voltage range(V)
60-500VDC
Max. charge/discharge current (A)
50A/50A
Total voltage measurement accuracy
±1.0%FSR
Total voltage measurement channel
2
Current measurement range
-65A~+65A
Insulation measurement accuracy
±5%@≤100KΩ
Communication interfaces
RS485/CAN
Available SOC range
10%~100%
Charge/Discharge efficiency (%)
>98
Operating temperature (°C)
-10 ~ 50
Storage temperature (°C)
-20 ~50
Humidity
10%~90%
Weight (kg)
4.5±1 kg
Dimensions (L*W*H) (mm)
443*410*116
