6
CHARGING THE BATTERY PACK (FOR P/N 420-L06R, -T09R ONLY)
Begin by plugging the AC-DC Adaptor into an outlet. The Charge Indicator will
then turn solid green.
1. Plug the Barrel Connector into the Battery Pack. Once plugged in, the
Charge Indicator on the AC-DC Adaptor, will turn solid red to indicate that
it is charging.
Once fully charged, the Charge Indicator (located on the AC-DC
Adaptor) will change back to solid green.
Charging time will be approximately 3.5 hours.
Continuously charging (leaving the Command plugged in) could damage
the Battery Pack and lead to decreased battery life. Do not charge
the headlamp for more than 7.5 hours at a time.
If your FoxFury rechargeable headlamp has been un-used for 10 to 15
days, then charge for 1.5–2 hours before extended use.
COMMAND
+
LO•PRO RECHARGEABLE
MODE BATTERY LIFE LUMENS
LOW POWER 10 hours 32
MEDIUM POWER 5 hours 78
HIGH POWER 3 hours 100
COMMAND RECHARGEABLE
1
1
