Foxtech EH10 10X User Manual

3.2 Serial Port / TTL Control
Gimbal Camera Cable
PC
RX GND TX
RX (White)
TX
RX
GND
TX (Green)
GND (Black)
8) Multi: Backup channel
TTL communication requirements: TTL signal is 3.3V, baud rate:
115200, data bit 8, stop bit 1, no parity, HEX send and receive.
Low Gear
Position 1
Middle Gear
Position 2
High Gear
Control Box
USB to TTL Cable
Position 3
Connection Diagram (Standard Version)
Connection Diagram (PC - USB to TTL Cable- Gimbal Camera as
example):
EH10 10X Optical Zoom Camera User Manual
@2022 FOXTECH All Rights Reserved 16
