BT705 Battery Analyzer User’s Guide - English Version_V1.00
Example:
NOTE
Test results do not necessarily indicate a faulty component or system.
Important
IMPORTANT indicates a situation which, if not avoided, may result in damage to the test
equipment or vehicle.
Example:
IMPORTANT
Do not soak product as water might find its way into the tester.
2 Introductions
The latest BT-705 Battery Analyzer from Foxwell is dedicatedly developed to test 6V & 12V
regular flooded, AGM flat plate, AGM spiral and gel batteries and 12V & 24V starting and
charging system. It provides a quick, easy and affordable solution for technicians to check
battery health and detect faults of starting and charging system. Main functions include battery
test, cranking test, and charging system test.
2.1 Tester Descriptions
This section illustrates external features, ports and connectors of the tester.
