N45 AM1S
1. Heat exchanger - 2. Coolant filler cap - 3. Oil filler cap - 4. Engine
air inlet manifold - 5. Injection pump - 6. Air filter - 7. Fuel outlet
connector to tank - 8. Fuel inlet manifold from tank - 9. Hand pump -
10. Oil dipstick - 11. Fuel filter with condensation drainage plug -
12. Fan.
N45 AM1S
1. Lifting U-bolt - 2. Exhaust manifold - 3. Oil vapour bleeder -
4. Exhaust outlet - 5. Lifting U-bolt - 6. Coolant outlet manifold from
engine - 7. Location of thermostatic valve - 8. Engine coolant inlet
connector sleeve - 9. Alternator - 10. Lubricant oil discharge plug -
11. Oil filter - 12. Electrical starter motor.
1
101112 89 7
2 3 4
5
6
1
1112 10 9 8
2 3 4 5 6 7
