EXTRAORDINARY MAINTENANCE - HOW TO
PROCEED
Adjustment of valve/rocker arm clearance
The adjustment of the clearance between the rocker arms and the
intake and exhaust valve control rods must be strictly carried out using
an Allen wrench (1), box-end wrench (3) and a feeler gauge (2).
For details refer to the Technical Repair Manual.
The values to be checked are detailed below:
Intake valve: 0.25 ± 0.05 mm
Exhaust valve: 0.50 ± 0.05 mm
Replace the belt if it shows signs of abrasion, cracks or
tears or if it is soiled with oil or fuel.
