FPZ-MI-R-MD-MOR-GOR-IE2-15-R03 4 / 119
INGOMBRI
R20-MD / R30-MD / R40-MD MOR
DIMENSIONS
DIMENSIONS
DIMENSIONES
ABMESSUNGEN
DIMENSÕES EXTERIORES
Misure in mm, Dimensions in mm, Dimensions en mm, Medidas in mm, Abmessungen in mm, Dimensões em mm
Mod
a
b
c
d
e
f
g
H*
i
m
n
o
p1
q
r
s
t
u
Peso
1
Weight
Gewicht
max
[kg]
R20-MD
283
309
167
47
235
210
G 1"¼
340
90
10
150
200
345
18
45
22
M6
150
21
R30-MD
319
346
187
47
235
210
G 1"¼
390
90
10
150
200
354
18
45
22
M6
180
25
R40-MD
350
372
197
47
235
210
G 1"¼
440
90
10
150
200
364
18
45
22
M8
225
40
*
Il valore indicato è riferito alla macchina con motore di lunghezza massima.
1
Il valore indicato è riferito alla macchina con il motore elettrico
*
The value indicated refers to the machine with motor of maximum length.
1
The value indicated refers to the machine with electric motor
*
La valeur indiquée prend en considération une machine équipée du moteur le plus long.
1
La valeur indiquée prend en considération une machine équipée d'un moteur électrique
*
El valor indicado se refiere a la máquina con motor de longitud máxima.
1
El valor indicado se refiere a la máquina con motor eléctrico
*
Der angegebene Wert bezieht sich auf das Gerät mit Motor mit max. Länge.
1
Der angegebene Wert bezieht sich auf das Gerät mit Elektromotor
*
O valor indicado refere-se a máquina com motor de comprimento máximo.
1
O valor indicado refere-se a máquina com o motor eléctrico.
