FPZ SCL K09 MS-MOR - Page 7

FPZ-MI-K-MS-MOR-USA-15-R03 7 / 84
DIMENSIONS
(K07-MS/K08-MS/K09-MS/K10-MS/K11-MS/K12-MS)
DIMENSIONES
DIMENSIONS
INGOMBRI
Dimensions in in, Medidas in in, Dimensions en in, Misure in in
Model
a
b
c
d
e
f
G
H max
K07-MS
16.69
18.94
10.59
3.23
18.43
17.24
3" NPT
18.37
K08-MS
17.99
19.61
10.59
3.23
18.82
17.64
3" NPT
19.15
K09-MS
19.37
22.09
12.40
3.78
20.00
18.82
4" NPT
23.74
K10-MS
20.31
22.56
12.40
3.78
20.00
18.82
4" NPT
24.61
K11-MS
21.34
23.74
13.07
3.58
21.26
20.00
4" NPT
24.81
K12-MS
21.57
23.82
13.07
3.58
21.26
20.00
4" NPT
24.92
Model
I
m
n
p1
p2
q
r
o
K07-MS
6.10
0.51
11.81
20.16
10.04
0.98
5.39
13.78
K08-MS
6.10
0.51
11.81
20.16
10.04
0.98
5.39
13.78
K09-MS
7.17
0.51
11.81
23.07
11.81
0.98
7.83
13.78
K10-MS
7.17
0.51
11.81
23.07
11.81
0.98
7.83
13.78
K11-MS
7.87
0.51
11.81
23.58
12.01
0.98
8.03
13.78
K12-MS
7.87
0.51
11.81
23.58
12.01
0.98
8.03
13.78
Model
s
t
u
v
w
x
z
K07-MS
0.20
M8
11.61
17.44
18.94
7.20
0.63
K08-MS
0.20
M8
12.20
17.44
18.94
7.20
0.63
K09-MS
0.20
M8
14.17
19.88
21.89
8.46
0.63
K10-MS
0.20
M8
14.17
19.88
21.89
8.46
0.63
K11-MS
0.20
M8
15.35
20.08
21.89
8.66
0.63
K12-MS
0.20
M8
15.35
20.08
21.89
8.66
0.51
