FPZ SCL K09 MS-MOR - Page 6

FPZ-MI-K-MS-MOR-USA-15-R03 6 / 84
DIMENSIONS
(K03-MS/K04-MS/K05-MS/K06-MS)
DIMENSIONES
DIMENSIONS
INGOMBRI
Dimensions in in, Medidas in in, Dimensions en in, Misure in in
Model
a
b
c
d
e
f
G
H max
K03-MS
9.49
10.55
5.79
1.69
9.06
8.07
1" 1/2 NPT
11.97
K04-MS
11.22
12.40
6.77
1.93
10.04
8.86
1" 1/2 NPT
13.78
K05-MS
12.87
14.37
7.87
2.13
12.60
10.24
2" NPT
14.40
K06-MS
14.80
15.47
8.07
2.13
12.80
11.42
2" NPT
14.45
Model
I
m
n
o
p1
p2
q
r
K03-MS
3.39
0.39
3.27
5.59
8.07
5.51
0.71
2.95
K04-MS
4.02
0.47
3.74
6.73
8.74
6.30
0.71
2.76
K05-MS
4.72
0.59
4.53
10.43
12.60
9.06
0.71
3.86
K06-MS
4.92
0.59
5.51
10.71
13.15
9.61
0.71
3.35
Model
s
t
u
v
w
x
z
K03-MS
0.16
M6
5.51
7.09
7.40
4.17
0.47
K04-MS
0.16
M6
6.89
7.68
7.40
4.72
0.71
K05-MS
0.16
M8
7.87
12.99
11.22
7.24
0.75
K06-MS
0.16
M8
9.45
13.07
11.22
7.80
0.75
