FPZ SCL K09 MS-MOR - Page 5

FPZ-MI-K-MS-MOR-USA-15-R03 5 / 84
Model
N
3500 rpm
[HP]
N
2900 rpm
[HP]
Q max
3500 rpm
[cfm]
Q max
2900 rpm
[cfm]
ΔP max
3500 rpm
[in Hg]
ΔP max
2900 rpm
[in Hg]
Leq¹
3500 rpm
(Lp)
[dB(A)]
Leq¹
2900 rpm
(Lp)
[dB(A)]
Weight²
max
[lbs]
Ps max
[in Hg]
K03-MS
0.75
0.75
52
43
4.7
3.7
61
59
24.3
53.1
1
1
52
43
5.9
4.9
61.3
59.3
26.5
53.1
K04-MS
1.5
1.5
97
80
4.3
5.9
63.8
61.8
36.4
53.1
2
2
97
80
6.3
6.6
64
62
43
53.1
3
-
97
80
7.4
-
64.2
-
49.6
53.1
K05-MS
2
2
155
129
3.8
5.1
69.5
67.5
51.8
59
3
3
155
129
6.6
7.1
69.8
67.8
58.4
59
4
4
155
129
8.1
-
70.1
-
67.2
59
K06-MS
3
3
215
178
3.7
4.8
72
70
68.7
59
4
4
215
178
5.5
7
72.3
70.3
71.65
59
5.5
5.5
215
178
8.1
8.1
72.6
70.6
77.6
59
6.2
-
215
178
9.6
-
72.9
-
77.6
59
K07-MS
4
4
294
243
3.7
4.6
77.7
75.7
103
82.7
5.5
5.5
294
243
5.6
6.3
78
76
107
82.7
7.5
7.5
294
243
9.6
8.9
78.3
76.3
145.7
82.7
10
10
294
243
11.1
-
78.6
-
154.5
82.7
K08-MS
5.5
5.5
381
315
2.9
3.8
78.8
76.8
115.7
82.7
7.5
7.5
381
315
5.9
6.6
79.1
77.1
154.3
82.7
10
10
381
315
8.5
9.2
79.4
77.4
163.1
82.7
15
15
381
315
11.1
-
79.7
-
184
82.7
K09-MS
7.5
7.5
471
390
3.7
4.6
79.3
77.3
166.5
82.7
10
10
471
390
5.9
7
79.6
77.6
175.1
82.7
15
15
471
390
10.3
10.4
80.1
78.1
196.2
82.7
20
20
471
390
11.1
-
80.4
-
269
82.7
K10-MS
7.5
7.5
556
460
2.7
3.8
79.4
77.4
170.9
82.7
10
10
556
460
4.7
5.9
79.7
77.7
179.5
82.7
15
15
556
460
8.8
9.9
80.2
78.2
200.6
82.7
20
20
556
460
11.1
-
80.5
-
273.4
82.7
25
25
556
460
-
-
-
-
298.7
82.7
K11-MS
10
10
650
538
2.9
3.9
82
80
194.9
82.7
15
15
650
538
6
7.1
82.5
80.5
216
82.7
20
20
650
538
11.1
10.4
83
81
288.8
82.7
25
25
650
538
-
-
-
-
313.1
82.7
K12-MS
15
15
726
601
3.8
6.6
83.5
81.5
223.7
82.7
20
20
726
601
6.3
9.6
84.3
82.3
296.5
82.7
25
25
726
601
10.3
-
87.2
-
320.8
82.7
1
Noise measured at 1 m distance with inlet and outlet ports piped, in accordance to ISO 3744
Rumorosidad medida a 1 m de distancia de los puertos de admisión y descarga, según la Normativa ISO 3744.
Niveau de bruit mesuré a 1 m de distance, conduits d’aspiration et refoulement raccordés selon la norme ISO 3744
Rumorosità misurata alla distanza di 1 m con aspirazione e mandata canalizzate, secondo la Normativa ISO 3744
2
Value refers to the weight of the machine with 3 Phase motor if MOR range, without motor if GOR or GVR range.
El valor indicado se refiere al equipo con motor trifásico para la ejecución MOR. Sin el motor eléctrico para las ejecuciones GOR y GVR.
Le valeur se refère à la turbine 3-phasé en execution MOR et GOR/GVR pour la turbine sans moteur.
Il valore indicato è riferito alla macchina con motore trifase per esecuzione MOR, senza il motore elettrico per esecuzioni GOR e GVR.
N: Installed motor power
Q: Flow rate
ΔP: Differential pressure
Leq: Noise
Ps max A: Maximum absolute pressure
N: Potencia instalada
Q: Caudal
ΔP: Presión diferencial
Leq: Rumorosidad
Ps max A: Pressão máxima absoluta
N: Puissance installé
Q: Débit
ΔP: Pression différentielle
Leq: Niveau sonore
Ps max A: Pression absolute maxi
N: Potenza installata
Q: Portata
ΔP: Pressione differenziale
Leq: Rumorosità
Ps max A: Pressione max assoluta
ASPIRATION
PERFORMANCE TABLE
EN
ASPIRACIÓN
DATOS CARACTERÍSTICOS
ES
ASPIRATION
CARACTÉRISTIQUES TECHNIQUES
FR
ASPIRAZIONE
DATI CARATTERISTICI
IT
