COMPRESSION
12
PERFORMANCE TABLE
EN
COMPRESION
DATOS CARACTERÍSTICOS
ES
COMPRESSION
CARACTÉRISTIQUES TECHNIQUES
FR
COMPRESSIONE
DATI CARATTERISTICI
IT
Mod
N
3500 rpm
[HP]
N
2900 rpm
[HP]
Q max
3500 rpm
[cfm]
Q max
2900 rpm
[cfm]
ΔP max
3500 rpm
[in WG]
ΔP max
2900 rpm
[in WG]
Leq¹
3500 rpm
(Lp)
[dB(A)]
Leq¹
2900 rpm
(Lp)
[dB(A)]
Weight²
max
[lbs]
Ps max
[in hg]
K03-MS
0.75
0.75
52
43
64
60
62
60
24.3
53.1
1
1
52
43
95
77
62.3
60.3
26.5
53.1
K04-MS
1.5
1.5
97
80
58
80
64.8
62.8
36.4
53.1
2
2
97
80
85
100
65
63
43
53.1
3
-
97
80
120
-
65.2
-
49.6
53.1
K05-MS
2
2
155
129
52
70
70.5
68.5
51.8
59
3
3
155
129
90
110
70.8
68.8
58.4
59
4
4
155
129
128
120
71.1
69.1
67.2
59
K06-MS
3
3
215
178
50
65
73
71
68.7
59
4
4
215
178
75
95
73.3
71.3
71.65
59
5.5
5.5
215
178
110
140
73.6
71.6
77.6
59
6.2
-
215
178
132
-
73.9
-
77.6
59
K07-MS
4
4
294
243
50
63
78.7
76.7
103
82.7
5.5
5.5
294
243
75
86
79
77
107
82.7
7.5
7.5
294
243
130
138
79.3
77.3
145.7
82.7
10
10
294
243
181
161
79.6
77.6
154.5
82.7
K08-MS
5.5
5.5
381
315
40
52
79.7
77.7
115.7
82.7
7.5
7.5
381
315
80
90
80
78
154.3
82.7
10
10
381
315
115
125
80.3
78.3
163.1
82.7
15
15
381
315
181
181
80.6
78.6
184
82.7
K09-MS
7.5
7.5
471
390
50
63
80.2
78.2
166.5
82.7
10
10
471
390
80
95
80.5
78.5
175.1
82.7
15
15
471
390
140
155
81
79
196.2
82.7
20
20
471
390
181
181
81.3
79.3
269
82.7
K10-MS
7.5
7.5
556
460
36
51
80.1
78.1
170.9
82.7
10
10
556
460
64
80
80.5
78.5
179.5
82.7
15
15
556
460
120
135
81
79
200.6
82.7
20
20
556
460
167
191
81.4
79.4
273.4
82.7
25
25
556
460
211
201
81.6
79.6
298.7
82.7
K11-MS
10
10
650
538
40
53
82
80
194.9
82.7
15
15
650
538
82
97
82.4
80.4
216
82.7
20
20
650
538
125
141
82.7
80.7
288.8
82.7
25
25
650
538
162
201
85.6
83.6
313.1
82.7
K12-MS
15
15
726
601
52
90
82.9
80.9
223.7
82.7
20
20
726
601
85
130
83.2
81.2
296.5
82.7
25
25
726
601
140
160
86.1
84.1
320.8
82.7
1
Noise measured at 1 m distance with inlet and outlet ports piped, in accordance to ISO 3744
Rumorosidad medida a 1 m de distancia de los puertos de admisión y descarga, según la Normativa ISO 3744.
Niveau de bruit mesuré a 1 m de distance, conduits d’aspiration et refoulement raccordés selon la norme ISO 3744
Rumorosità misurata alla distanza di 1 m con aspirazione e mandata canalizzate, secondo la Normativa ISO 3744
2
Value refers to the weight of the machine with 3 Phase motor if MOR range, without motor if GOR or GVR range.
El valor indicado se refiere al equipo con motor trifásico para la ejecución MOR. Sin el motor eléctrico para las ejecuciones GOR y GVR.
Le valeur se refère à la turbine 3-phasé en execution MOR et GOR/GVR pour la turbine sans moteur.
Il valore indicato è riferito alla macchina con motore trifase per esecuzione MOR, senza il motore elettrico per esecuzioni GOR e GVR.
N: Installed motor power
Q: Flow rate
ΔP: Differential pressure
Leq: Noise
Ps max A: Maximum absolute pressure
N: Potencia instalada
Q: Caudal
ΔP: Presión diferencial
Leq: Rumorosidad
Ps max A: Pressão máxima absoluta
N: Puissance installé
Q: Débit
ΔP: Pression différentielle
Leq: Niveau sonore
Ps max A: Pression absolute maxi
N: Potenza installata
Q: Portata
ΔP: Pressione differenziale
Leq: Rumorosità
Ps max A: Pressione max assoluta
