AQUALINE PROTRONIC Urinal Flush Valve, Basic Installation Kit
Please refer to the graphics in the German Installation and Operating Instructions.
0 Table of Contents
1. Abbreviations and Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of Product
4. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7. Installation Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
8. Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1. Abbreviations and Units
2. Warranty
Liability is accepted according to the general terms of agreement and supply. Only
use original AQUA replacement parts.
DN Nominal diameter in mm
FAR-Best.-Nr. Franke-Aquarotter Order No.
EA-Nr. European Article Number
Conversion 1 mm = 0.03937 inches
1 inch = 25.4 mm
All length specifications in the graphics are in mm.
