3. Important Notes
• Installation, commissioning and maintenance are to be performed only by a
qualified technician according to the instructions provided and in accordance with
legal requirements and acknowledged rules of technology.
• All technical connection regulations specified by the local water and electricity
supply utility companies must be complied with.
• The following applies to fittings with a 230 V mains connection:
Secure the electric connection with an earth leakage circuit breaker (RCD).
• All rights reserved to make technical alterations.
4. Application
Basic installation kit to complete kits (optional):
AQUALINE - Urinal flush valve DN 15 for in-wall installation
Order No.:
2000066005 .... AQUALINE urinal pushbutton flusher DN 15
AQUA PROTRONIC
Opto-electronically controlled urinal flushing valve DN 15 for in-wall mounting
Order No.:
2000067729 .... with integrated transformer (230 V AC)
2000067733 .... for separate voltage supply (24 V DC)
2000066123 .... with battery operation (6 V)
2000101340 .... A3000 open (24 V DC)
5. Scope of Delivery
6. Dimensions
7. Installation Example
A: Front edge of tiles
Item Description
1 Flush-mounting cabinet with compact function block,
integrated blockable water volume flow regulator and
flush-plugs
2 Shell protection with 2 cylinder head screws
Installation and Operating Instructions
