604
340
193
∅120
560
272
540 60
70-180
i
Installation and technical data Page 18
Prepare a stable, ergonomic surface (min. load capacity: 100 kg or 220 lb).
The operator panel should be no higher than at eye level.
Minimum clearances:
▪ To the rear wall: 50 mm
▪ Upwards: 200 mm (fi lling and removal of coff ee bean hopper)
▪ To the right: 60mm (for removal of the brewing unit)
▪ To the left: 60mm (for opening the refrigeration unit)
Adjustable feet (optional) can be used to compensate for unevenness or
height diff erences.
If optional add-on units are installed, up to an additional 330mm of width
may be required.
Buff et feed-through for grounds ejection
Installation dimensions of the A200 Dimensions of the A200
Total height
40 mm 600mm+40mm=640mm
100 mm 600mm + 100mm=700mm
Adjustable feet
≥ 50 ≥ 60
≥200
