– 5 –
EN
3
4
5
6
8
1
Technical data
Operating data Value
Operating pressure (ideal) 60 PSI 4.1 bar 410 kPa
Operating pressure (max.)* 125 PSI 8.6 bar 860 kPa
Operating pressure (min.)* 20 PSI 1.4 bar 140 kPa
Water temperature (ideal) 140°F 60°C
Water temperature (max.) 158°F 70°C
Hole Size For Faucet 1 3/8“ 35mm
10
11
12
9
13
2
7
NOTE: Contact us immediately if you see
inconsistencies.
phone: (1- 800-626-5771)
website: www.franke.us/ks
email: ks-customerservice.us@franke.com
FFPD5400 Series
1 - Faucet Assembly
2 - Aerator Keys
3 - Plastic Flange
4 - Rubber Washer
5 - Fixing Plate
6 - Fixing Nut
7 - Supply hoses
8 - Check Valve Holders
9 - Filtered water supply fitting
10 - 3/8“ poly tubing
11 - Hex Key
12 - Spout Set Screw
13 - Shut off valve
Certifies this faucet complies with ASME A112.18.1 / CSA B125.1 & NSF 61, NSF 372
and AB1953. The faucet also complies with water usage requirements of the
California Energy Comission and the US Department of Energy.
