UVC-System Instruction manual
5
Operating panel
I2 locks for front flap
A main switch
J screws for control component
B buzzer
P aerosol filter (Franke filter)
C on-off button
D front flap
E control
H hinge with safety switch
H1 screw head (safety switch)
