Franke uvc-26 - Operating Panel

UVC-System Instruction manual
4
Operating panel
M mesh filter
A main switch
N Airflow filter
B buzzer
O cover
C on-off button
P aerosol filter (Franke filter)
D front flap
E control
F UVC lamp
G socket for UVC lamp
H hinge with safety switch
H1 screw head (safety switch)
I2 locks for front flap
J screws for control component
K throttle control spring
L gasket
M
O
G
F
L
K
H
D
N
Fig. 1
