HARDWARE AND CORRESPONDING BASES
MOUNTING HARDWARE FOR BASES, IN-GROUND & SURFACE MOUNTS
You may receive additional mounting hardware with your umbrella that is not needed for specific
mounting selection. Please see the specific mounting installation pages in this manual for your
specific hardware needed, and detailed mounting instructions.
2” X .5” (8MM ALLEN KEY)
1.4” X .5” (8MM ALLEN KEY)
.75” X .5” (8MM ALLEN KEY)
6MM (GUIDE PINS & GRUB-SCREWS)
8MM (MOUNTING HARDWARE)
GUIDE PINS
1:1 SCALE
SCAN THE QR-CODE FOR VIDEO TUTORIAL
SCAN THE QR- CODE FOR THE VIDEO TUTORIAL ON HOW
TO PROPERLY AND EFFICIENTLY STACK THE G-PLATES
USING FRANKFORD GUIDE PINS.
PLEASE BE AWARE OF HARDWARE NEEDED FOR SPECIFIC BASES. NOT ALL HARDWARE WILL WORK WITH ALL BASE
CONFIGURATIONS AND OR MOUNTS.
03
04
TRIPLE GALVANIZED PLATE STACK
• 40GX3
• 36G-SQX3
• DECK PLATE (SURFACE MOUNTING)
• IG (IN-GROUND MOUNTING)
• ECU-480 ROLLING BASE
• NGU-550 HD BASE
HARDWARE AND CORRESPONDING BASES
GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES DURING
SHIPPING AND STORAGE. THEY MUST BE REMOVED AND DISCARDED BEFORE THE
INSTALLATION OF ANY UMBRELLA.
DOUBLE GALVANIZED PLATE STACK
• NOT FOR USE WITH ANY ECLIPSE CANTILEVER BASE
OPTIONS
