Control Box (behind fi'ont cove 0
©
Clean
Ice size
adjust
_ode
Ice full
©
Ice
making
©-
_Cee st
Red LED
Green LED
J
Yellow LED
Descriptions of LEDs and buttons:
.
Red LED" Ice Full indicator light.
When this LED is lit, the ice storage bin is full of ice or there is something between
the two arms of the ice-full sensor in the ice storage bin. The unit will stop working.
When ice cubes are taken out of the ice storage bin, clearing the sensor, the red LED
will keep flashing for 3 minutes. Then the unit will restart and return to the ice
making mode.
.
Green LED: Ice Making indicator light.
When this LED is lit, the unit is working in the Ice Making mode controlled by a
temperature probe on the evaporator. When the green LED is flashing, the unit is
working in the Ice Making mode controlled by a fixed timer.
24
