16
Description
Connector Standard (EV side) IEC 62196-2
Power supply plug E/F (G in UK, J in Switzerland)
EVSE Standard IEC 61851
CE Mark Y
Warranty 2 years
Recharging Mode plug and cable connected
permanently connected
(
plug and cable connected
if installed in France
)
TÜV Certication Y Y
Electrical Specs and connection
Maximum Power [kW] up to 2.3* up to 7.4*
Voltage [V / Hz] 230 / 50, single-phase 230 / 50, single-phase
Current [A] up to 10* up to 32*
Stand-by consumption [W] < 2 < 2
Cable with connector Type 2 (EV side) Y, tethered included
Cable with connector Type 2 Length [m] 3/5
Power Supply cable [m] 6 N.A.
*
The values may vary in some countries according to local applicable standards.
General Specs
Enclosure ratings IP54, IK08 (IEC 60529)
Overall body dimensions [mm]
335 x 277 x 95 (w/o Plug)
335 x 277 x 350 (with plug)
Housing Polycarbonate
Weight [kg] ~ 4
Standard Body colour Black (RAL 9011) and White (RAL 9003)
Status indication Y, led RGB
Safety and Operation
Temperature range [°C] -25 / +50 (without direct exposure to sunlight)
Overheating protection Y
Humidity Resistance Y, full coated
Class of Protection I
Pollution Degree PD3
Overvoltage category OVC III
Housing re ratings UL94 V-0
Residual current monitoring Y, 6 mA DC sensitive RCM device included for DC-leakage detection
Maximum installation height [m] 2000 a.s.l.
Connectivity & Special Features
Bluetooth Y
Smartphone App Free2Charge, compatible with Android, IOS
Android version compatibility*** Lollipop (5.0) or higher
IOS version compatibility** 12 or higher
Communication Protocol Proprietary
Dynamic Power Management Y, by installing the included sensor
**
Data refer to the rst release of the APP and may vary with future evolution.
***
NOT compatible with Android 6.
3.3. Technical features of the charging device
is a charging device for electric vehicles designed and certicated up
to 7.4 kW.
if installed in if installed in
Plug&Play Power Upgrade
