    What to do if my Freedom Enterprise MisMatcher Delux Music Pedal has no video output?
    • F
      fgarciaAug 7, 2025
      If your Freedom Enterprise Music Pedal isn't displaying video, make sure the unit is powered on. Confirm that you're using RCA cables in the top RCA ports, as RCA to 3.5mm cables commonly found with video cameras are not compatible. Also, ensure you’re using proper 3.5mm TS or TRS patch cables for patching, with signal on the Tip. Double-check your patching as well.
  • C
    Chelsea KelleyAug 13, 2025
    How to fix unstable video on Freedom Enterprise Music Pedal?
    • R
      Rachel StevensAug 14, 2025
      To stabilize the video on your Freedom Enterprise Music Pedal: * Patch the Sync Mixer after the Enhancer to restore video sync. * Make sure the Sync Mixer knob isn’t fully counter-clockwise. * Reduce the Gain, Feedback 1, and Feedback 2 knobs.
  • J
    jjonesAug 21, 2025
    What to do if Freedom Enterprise MisMatcher Delux Music Pedal doesn’t power on?
    • B
      Brian HerreraAug 22, 2025
      If your Freedom Enterprise Music Pedal isn't powering on, try using both the Micro USB and USB-C power ports. If that doesn't work, replace the Micro USB / USB-C cable. As a last resort, replace the power adapter.
  • M
    Matthew JacksonAug 29, 2025
    Why is my Freedom Enterprise Music Pedal not reacting to the Gate inputs?
    • S
      Sabrina DavisAug 29, 2025
      If the Gate inputs on your Freedom Enterprise Music Pedal aren't reacting, ensure you're using patch cables with the Gate signal on the Tip. Also, verify that the Gate signal is more than 3V and less than 10V.

Summary

WARNING

Cables

Quick Start

Controls - Misc

Controls - I;O

Controls - Passive Mixers; Attenuators

Controls - Enhancer

Controls - Sync Mixer

Principle of Operation

Patching Examples - 1

Patching Examples - 2

Patching Examples - 3

Patching Examples - 4

Patching Examples - 5

Patching Examples - 6

Patching Examples - 7

Troubleshooting

Specifications

Warranty

Freedom Enterprise MisMatcher Delux Specifications

General IconGeneral
DC Input5 V
Power Consumption350 mA @ 5 V
Gate Input[3;10] V, 5 V nominal
Video Level Input / Output2 V, 75 ohm termination pk-pk
Video FormatNTSC, PAL, SECAM
