3. Patch IAR EW for ARM V6.4.20 or later, to make it compatible with OpenSDA Debug
• Copy the content of the folder “development tool patches\IAR_patch_v110\patch”
from the FRDM-KL25Z_v1.00 zip file in the directory [Embedded Workbench
path]\arm\bin\
4. Run IAR EW for ARM V6.4.20 or Later and build the project
• Run IAR Embedded Workbench V6.4.20 or later, by selecting it from the Windows
Start menu
• Select File, Open and Workspace
• Select blinky.eww available in the “Project Example\build\iar\blinky” folder from the
FRDM-KL25Z_v1.00 zip file then Open
Quick Start Guide
• Right click on Blinky freedom - FLASH_128KB (top left box) then Select Options
- General Options, Target, SELECT Core “Cortex-M0+”
- C/C++ Compiler, List, DESELECT options “Output list file” & “Output assembler file”
- Assembler, List, DESELECT option “Output list file”
- Debugger, Setup, SELECT Driver “PE micro”
- Debugger, Download, Select then “FlashKLxx128K.board” and “Open”
- PE micro / Setup, SELECT P&E Hardware Interface Type “Tracelink - USB”
- PE micro / Setup, CHANGE JTAG/SWD speed value with 500kHz, then press “OK”
• Select Project then “Clean”
• Select Project and “Rebuild All” or press
NOTE : During the compilation some warning messages may appear
Preliminary
