Freetime 933101 - Table of Contents; Parts List; Drawing & Tools You will Need

2
CONTENTS
Parts List ...................................................2
Drawing & Tools You Will Need ................2
Tent Orientation on Your Vehicle ..............3
Assembly Instructions ..............................4
Mounting Extrusion to the tent base .......4
Fitting the tent to roof rack ......................4
Tent set up instructions ............................5
Tent Close Instructions .............................7
Storage & Handling guideline ..................7
MATERIAL
Fabric
High quality Rip-stop poly-cotton fabric
UV protected-breathable, waterproof &
mould resistant.
Polyester fl ysheet
Incorporated & attached to the tent via
steel rods.
Base
Aluminium Alloy on both top & bottom surfaces
with a foam insulation core.
Mattress
Comfortable 65mm HDPE mattress with
removable cover.
SPECIFICATIONS
Size: 2400 L x 1400 W x 1300 H (mm)
- Open size
1200 L x 1400 W x 280 H (mm)
- Closed size
Gross Weight: 50kg
FEATURES
• Fast & easy set up means sleep-easy
camping on-road or off-road.
• Ultra-fi ne mesh door & windows provide a
great night’s sleep away from insects.
• Sturdy Aluminium Alloy ladder retractable to
suit the height of the roof-rack.
• Easy storage - simply fold the tent, zip-on the
cover and drive away.
• Free up vital storage space in the vehicle.
PARTS LIST
• Roof-top Tent with Base x 1
• Mounting Extrusions x 2
• Extrusion Mounting Brackets
(6mm bolts, nuts & washers x 4 sets) x 4
• Tent Mounting Brackets
(8mm bolts, nuts & slide plates x 4 sets) x 4
• Alloy Ladder x 1
• Ladder Mounting Brackets x 2
TOOLS YOU WILL NEED
• Screwdriver - Blade & Phillips /
Cordless Drill & Bits.
• 14mm Spanner & 200mm Adjustable Wrench
• Hacksaw (subject to mounting orientation
on your vehicle - refer to page 3)
