FREEWAY Transactive Xtra 200 - LCD Display Screen Functionality

999075 – Revision B Page | 31 of 48
LCD Display Screen Functionality
The table below includes the details on all user display messages, it also includes the LED colour, the audible beeping and
instructions on what actions to take when each message appears. This table may help for troubleshooting.
Display
Message
Message
explanation
LED
colour
Beep sound
Instruction
LOW Batt!
Battery Status LOW
Orange
1 Beep Repeat
Place Hoist on charge as soon as possible
C h arge d
Batteries Fully C h a r g e d
Green
None
Batteries full - remove from charging do c k
C h a rg i ng
Charging Currently
Active
Orange
flashing
None
None - Batteries are c h a r g in g
Up
Hoist Lifting Active
Green
None
None - Informative only
D ow n
Hoist Lowering Active
Green
None
None - Informative only
No Lim_Sw!
Limit Switch Fault
Green
Constant
Beep
Contact Service C en tr e
UP: I n hi b i t!
Battery Capacity TOO
LOW to Lift
Red
3 Beep Repeat
Place hoist on charge immediately
Up Lim_Sw!
Up Limit Switch Active
Green
None
None - Informative only,
press Down t o co n t in ue
Down Lim_Sw!
Down Limit Switch
Active
Green
None
None - Informative only,
press Up to co n t in ue
HIGH CURRENT
High Current D raw
from Hoist M o t o r
Green
Beep for 1
Second
Contact Service C en tr e
PM Due
Preventative
Maintenance D ue
Green
Beep every 30
minutes
Contact Service C en tr e
Table 10
