Servo introduction
EN
A servo or reversed servo is defined as follows:
When the servo input signal changes from 1000ųs to
2000ųs, if the servo arm rotates clockwise, it's a
positive servo. If it rotates counter clockwise, it's a
reversed servo.
i
Servo No.
2
3
4
5
6
8
B
attery Installation
-
'
�
j
j
j
j
I
U
g
g
g
g
I
-9-
The standard battery is:
4S 14.SV 4000mAh 35C
or
6S 22.2V 3700mAh 35C
The advised battery capacity and discharge rate is the
following:
4S 14.SV 3200mAh - 4S 14.SV 4500mAh
6S 22.2V 3200mAh - 6S 22.2V 4500mAh
Discharge rate of C ;, 25C
Different battery weights may affect the CG, check the CG if you
use a different size battery.
lift tape to
remove the
battery hatch
Battery
hatch
