12. Slide the elevator pushrods through the tubes and attach the plastic clevises. Center
the elevator servo and while holding the elevators in the neutral position, tighten the
connector screw on the servo horn with a screwdriver.
13. Apply 5-minute epoxy to the nose cone and attach it to the fuselage, making sure it
is aligned properly.
14. The hatch has magnets at the front and a tab at the back. Lift from the front and slide
f
orward to remove the hatch. Install your receiver using double sided tape or Velcro.
F9F Panther
Item No.:F1701 -5-
