30–01 Throttle Pedal Pivot Pin
Lubricating
Using a silicone spray, lubricate the throttle pedal
pivot pins as shown in Fig. 1 and Fig. 2.
07/09/2009
f300408a
1
2
3
2
1. Throttle Pedal
Assembly
2. Pivot Pins
3. Base Plate
Fig. 1, Floor-Mounted Throttle Pedal
07/09/2009
1
2
f300409a
1. Throttle Pedal Assembly
2. Pivot Pin (not shown)
Fig. 2, Suspended Throttle Pedal
Throttle Control 30
Recreational Vehicle Chassis Maintenance Manual, January 2010 30/1
