4. Install the drain plugs and tighten 25 lbf·in (282
N·cm).
5. Add approximately 1 to 1-1/2 pints (0.5 to 0.7 L)
of oil (80W–90 hypoid gear oil) to each hub.
6. Rotate the wheels, allow the oil to settle, and
check the levels.
IMPORTANT: Fill the hubs to the level indicators
on the hub caps, or to no more than 1/4 inch (6
mm) above the indicators. See
Fig. 11.
7. Install the filler plugs securely.
f330247b
A
1
2
07/09/2009
A. Hub Cavity Full
1. Fill Plug/Magnetic Drain
2. Drain Plug
Fig. 11, Oil-Filled Hub Cap
Front Axle 33
Recreational Vehicle Chassis Maintenance Manual, June 2015 33/7
