DESCRIPTIONS & SPECIFICATIONS
FUNCTIONAL DESCRIPTION
English
L
P
N
O
M
Q
A - Depth Adjustment Knob
B - Variable Speed Control
C - Micro Adjustment Knob
D - Turret Stop Rod
E - Side Handles
F - Coarse Adjustment Knob
G - Arrow Indicator
H - Turret Stop Rod Locking
Screw
I - Depth Stop Turret
J - Spindle
K - Spindle Lock (Shaft Lock)
A
I
F
H
B
C
E
G
D
K
J
R
L - Above Table Height Adjustment
Access
M - Depth Adjustment Wrench
N - Collet & Collet Nut
O - On/Off Trigger Switch
P - Plunge Locking Lever
Q - 22mm Collet Nut Wrench
R - Above Table Spindle Lock Access
