FRIDEN STW - Page 29

615-80
FRIDEN
CALCULATING
MACHINE
CO.,
INC.
Page
29
DIVISION
ADIUSTMENTS
85,
SENSING
FINGERS
ACTUATING
LEVER:
Machine
in
Normal
Positionand
Sensing
Fingers
B
pulled
down,
there
shouldbe
no
more
than .005
clearance
between
Lever
A
and
Sensing
Fingers
B.
Adjust
by
forming
Lever
C,and
keepLever
A
parallel
to
ends
of
Sensing
Fingers
B.
86.
CONTROL
SLIDEFOR
DIVISION
THROWOUT
ACTUATOR:
When
Divide
Keys
are
first
de-
pressed,
Slide
A
moves
to
the
left
to
place
Di-
vision
Throwout
Actuator
B
in
position
to
con-
tact
Roller
C
on
#6
Actuator,
Adjust
tail
of
D.
87,
DIVISION
SHIFT
REVERSING
LEVER,
LAST
POSITION:
If
Carriage
is
allowed
to
reach
the
last
position
in
a
Division
Aligner
operation,
the
Shift
Gear
will
make
an
override
action.
This
actuates
Lever
A
and
Bail
B
to
delatch
Latch
C.
Adjust
by
forming
Lip
of
Bail
at
B.
