Left
Wall
Φ2.7in
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Φ2.7in
Rear piping hole
QE:
QD:
Left
Wall
Φ
2.1in
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Φ
2.1in
Rear piping hole
QC:
Left
Wall
Φ
2.1in
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Φ
2.1in
Rear piping hole
Left
Wall
Φ2.1in
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Φ2.1in
Rear piping hole
QB:
25
Installation of indoor unit
Step one: choosing installation location
Step two: install wall-mounting frame
Provide recommendation to customer for the most ideal location to install unit.
1. When hanging wall mounting plate, be sure to set level, once level is set mark
all locations for mounting screws.
Drill holes and use appropriate mounting hardware. (Example: Wall Anchors,
Self Tapping Screws or other)
3. Affix wall mounting plate and ensure no flex from the wall surface to guarantee
secure mounting.
1. Choose the position of piping hole according to the direction of outlet pipe. The
position of piping hole should be a little lower than the wall-mounted frame,
shown as below.
Step three: open piping hole
2. Open a piping hole with the diameter of Φ2.1in or Φ2.7in on the selected outlet pipe
position.In order to drain smoothly, slant the piping hole on the wall slightly
downward to the outdoor side with the gradient of 5-10°.
To Next Page
