Max. length of connection pipe Unit: ft
31
1. Standard length of connection pipe
●
15ft, 22.5ft,24ft
4.
Additional refrigerant may be required when extending the line-set.
●
After the line-set has been extended 33ft past standard length of 25ft,
adding additional 5ml of refrigerant oil for each additional 16ft.
● The calculation method of additional refrigerant charging amount (on the basis
of liquid pipe):
● Basing on the length of standard pipe, add refrigerant according to the
Additional refrigerant charge amount = extended length of liquid line x
required additional amount per foot.
2.
Min. length of connection pipe is 9Ft.
3.Max. length of connection pipe.
Configuration of connection pipe
45 75
45 90
45 90
60 90
75 90
Cooling
capacity
Max. length
of connec-
tion pipe
Cooling
capacity
Max. length
of connec-
tion pipe
5000Btu/h
7000Btu/h
9000Btu/h
12000Btu/h
18000Btu/h
24000Btu/h
28000Btu/h
36000Btu/h
42000Btu/h
48000Btu/h
requirement as shown in the table. The additional refrigerant charging amount
per foot is different according to the diameter of liquid pipe. See the
following sheet.
