ELECTRONIC CONTROL BOARD COMPONENTS IDENTIFICATION
Front
Sample board for Kuhl+ unit
Back
Reversing Valve
Max Speed
High Speed
Med Speed
Low Speed
T-stat Terminals
Transformer voltage
Selector Switch
115/230 Volts
Battery Compartment
User Interface
connector
Transformer
115/230 Volts
DISCHARGE
