Friedrich MC24Y3J Service Manual

1. Specification
Indoor
Model Name
MC24Y3J
MC36Y3J
Power Supply
V / Ø / Hz
1 / 208-230 / 60
1 / 208-230 / 60
Casing Color
-
-
-
Dimensions
Body
W x H x D
mm
204 × 840 × 840
288 × 840 × 840
W x H x D
inch
8-1/32 x 33-1/16 x 33-1/16
11-11/32 x 33-1/16 x 33-1/16
Net Weight
Body
kg (lbs)
20.5 (45.2)
24.6 (54.2)
Heat Exchanger
#1_(Row x Column x Fins per inch) x No.
-
(1 x 8 x 19) x 1
(1 x 12 x 21) x 1
#2_(Row x Column x Fins per inch) x No.
-
(1 x 8 x 19) x 1
(1 x 12 x 21) x 1
Face Area
m
2
(ft
2
)
0.168 (1.81)
0.252 (2.71)
Fan
Type
-
Turbo Fan
Turbo Fan
Air Flow Rate
H / M / L
m
2
/min
17.0 / 15.0 / 13.0
30.0 / 28.0 / 26.0
H / M / L
ft
2
/min
600 / 530 / 459
1,060 / 989 / 918
Fan Motor
Type
-
BLDC
BLDC
Output
W x No.
60 x 1
124 x 1
Power Input
W x No.
-
-
Running Current
A
0.60 x 1
0.72 x 1
Dehumidification Rate
ℓ/h (pts/h)
2.4 (5.1)
3.6 (7.7)
Sound Pressure Level
H / M / L
dB(A)
38 / 36 / 34
46 / 44 / 40
Sound Power Level
Cooling
H / M / L
dB(A)
-
-
Piping Connections
Liquid
mm(inch)
Ø 9.52 (3/8)
Ø 9.52 (3/8)
Gas
mm(inch)
Ø 15.88 (5/8)
Ø 15.88 (5/8)
Drain (O.D. / I.D.)
mm
Ø 32.0 / 25.5
Ø 32.0 / 25.5
Safety Devices
-
Fuse
Fuse
Power and Communication Cable (included Earth)
No. x mm
2
(AWG)
4C x 0.75 (18)
4C x 0.75 (18)
Decoration Panel
Model Name
-
PT-UMC1
PT-UMC1
Casing Color
-
Morning Fog
Morning Fog
Dimensions
W x H x D
mm
22 × 950 × 950
22 × 950 × 950
W x H x D
inch
7/8 x 37-13/32 x 37-13/32
7/8 x 37-13/32 x 37-13/32
Net weight
kg (lbs)
5 (11.0)
5 (11.0)
Note:
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Piping Length : Interconnected Pipe Length = 7.5m
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national code.
3. Due to our policy of innovation some specifications may be changed without notification.
4. Sound Level Values are measured at Anechoic chamber.
Therefore, these values can be increased (maximum 3dB(A)) owing to ambient conditions during operation.
Conversion Formula
kW = Btu/h x 0.0002931
cfm = CMM x 35.3
- 2 -
