131 PB

Figure 907

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

1 69700572 Front Grill MRM36Y3J 1

2 69700573 Front Panel Assy MRM36Y3J 1

4 69700574 Axial Flow Fan MRM36Y3J 1

9 69700575 Compressor MRM36Y3J 1

10 69700576 Electrical Heater MRM36Y3J 1

11 69700577 Magnet Coil MRM36Y3J 1

12 69700578 4-Way Valve Assy MRM36Y3J 1

14 69700579 Valve Support Sub-Assy MRM36Y3J 1

15 69700580 Cut-Off Valve MRM36Y3J 1

18 69700581 Handle Assy MRM36Y3J 1

20 69700582 Electronic Expansion Valve Sub-

Assy

MRM36Y3J 1

21 69700583 Temperture Sensor MRM36Y3J 1

22 69700584 Rear Grill MRM36Y3J 1

23 69700585 Condensor Assy MRM36Y3J 1

26 69700586 Motor Support Sub-Assy MRM36Y3J 1

27 69700587 Top Cover Sub-Assy MRM36Y3J 1

-28 69700588 Cable Cross Loop MRM36Y3J 1

32 69700589 Left Handle MRM36Y3J 1

34 69700590 Fan Motor MRM36Y3J 1

40 69700591 Electric Box Assy MRM36Y3J 1

-ITEMS ARE NON- ILLUSTRATED

*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME

PARTS CATALOG

Outdoor Unit MRM36Y3J
