Friedrich MRM12Y1J Service & Parts Manual

64 PB
Removal
Indoor Unit
Remove a service
cover mounting screw.
Open service cover
upward.
A switch for field setting is
not provided in particular.
screws
Screw stoppers inside the
flap which were equipped in
the existing models are not
provided.
a
Remove the 5 screws,
in the right and the left,
which fix the main body
with the front grille.
At the upper part there are 2
hooks in the left and the
right.
Disengage the hooks by
pressing knobs with a
screwdriver.
b
c
Disengage the 3 hooks
on the upper part.
In case that the hooks
are not pressed from
above, remove the front
panel and then remove
the grille while pushing
the hook through a
clearance between the
front grille and the heat
exchanger.
The front grille can be
removed in a manner to
pull out the upper part
forward and lift up the
lower part.
Hooks
Left
Center
Right

Friedrich MRM12Y1J Specifications

General

Cooling Capacity	12, 000 BTU
Energy Efficiency Ratio (EER)	11.0
Refrigerant	R-410A
Power Supply	115V/60Hz
Voltage	115V
Fan Speeds	3
Control Type	Electronic
Remote Control	Yes
Filter Type	Washable
Cooling Area (Sq. Ft.)	Up to 550
Dehumidification (Pints/Hr)	2.5 pints/hr
Amperage	9.8 A
