66 PB
Removal
Indoor Unit
Remove Pipe Clamp
a
b
Loosen the screws,
in the right and the left,
which fix the Evaporator
Assy. Remove Evaporator
Assy
Auxiliary piping
Piping fixture
Adjust the pipeline slightly
c
Auxiliary piping
Heat exchanger
