1.
2.
Condensate should drain easily from unit.
4.
Installation choice should be strong enough to handle the weight of the equipment and
insulate against vibration noise from operation.
5.
6.
7.
8.Follow installation requirements and dimensions.
1
.
Select a location with consideration of surroundings including pets and neighbors as heat
and cool will be discharged from equipment.
2
.
Select a location where there should be sufficient ventilation.
3
.
Select a location where there should be no obstructions cover the inlet and outlet.
4
.
The location should be able to withstand the full weight and vibration of the outdoor unit
and permit safe installation.
5
.
Select a dry place, but do not expose under the direct sunlight or strong wind.
6
.
3.
Keep system out of the reach of children and pets.
7.
8.
9.
Important Notices
Indoor Unit Placement
Air inlet and discharge should be kept free of obstruction at all times. Ensure airflow
through living space.
Be sure to leave enough space to allow access for routine maintenance. The height of the
installed location should be 8 ft or more from the floor.
Select a place
3 ft
or more away from TV or any other electric appliances.
Select a place where the filter can be easily taken out.
dimension diagram, convenient for maintenance, repair.
Select a place where it is out of reach for the children.
Select a place where will not block the passage and do not influence the city appearance.
Do not use the unit in the immediate surroundings of a laundry, bath, shower
or swimming pool
9.
Installation
Outdoor Unit
Placement
Make sure that the outdoor unit installation dimension with installation
are in accordance
tubing within .
33 ft
The height difference of connecting the tubing within
16 ft
, the length of connecting the
