Technical Information
6HUYLFH0DQXDO
5HIULJHUDQW6\VWHP'LDJUDP
Indoor unit
Outdoor unit
COOLING
HEATING
4-Way valve
Discharge
Suction
Heat
exchanger
(evaporator)
Heat
exchanger
(condenser)
Valve
Valve
Liquid pipe
side
Gas pipe
side
Accumlator
Compressor
Strainer StrainerCapillary
&RROLQJ+HDWLQJ0RGHOV
Refrigerant pipe diameter
Liquid :1/4" Gas : 3/8"
