Removal
Indoor Unit
Support the front panel by one
hand, while remove the rotation
axis at the upper center by the
other hand.
a
Draw out the axial bush.
Bend the horizontal louver
slightly and then remove it.
Left and right filters are
interchangeable.
To re-install, insert air filter
along the guide.
b
Hook a finger onto the
projection part provided
on the both sides of the
units panel and open
up the panel to the
position higher than it
will stop.
c
Remove the front panel
from the unit.
Guide Louver
Axial bush
