Friedrich Vert-I-Pak A-Series User Manual

6
Electrical Data and Specications
VEA
MODEL VEA09K VEA12K VEA18K
Heater Watts
2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090
Voltage
230/208 230/208 230/208
Elec. Heating Current (Amps)
12.0/11.1
16.0/14.6 22.9/20.9 12.0/11.1 16.0/14.6 22.9/20.9 12.0/11.1 16.0/14.6 22.9/20.9
Minimum Circuit Ampacity
15 19.9 28.6 15 19.9 28.6 15 19.9 28.6
Branch Circuit Fuse (Amps)
15 20 30 15 20 30 15 20 30
LRA - Compressor (Amps)
21.0 21.0 21.0 29.5 29.5 29.5 42.0 42.0 42.0
Cooling Current (Amps)
4.2/4.4 4.2/4.4 4.2/4.4 5.2/5.6 5.2/5.6 5.2/5.6 8.8/9.5 8.8/9.5 8.8/9.5
Basic Heater Size
2.5 kW 3.4 kW 5.0 kW 2.5 kW 3.4 kW 5.0 kW 2.5 kW 3.4 kW 5.0 kW
Power Connection
HARD WIRED HARD WIRED HARD WIRED
Recommended Branch
Circuit Wire Sizes
* AWG-American Wire Gauge
14 12 10 14 12 10 14 12 10
VHA 230/208
MODEL VHA09K VHA12K
Heater Watts
2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090
Voltage
230/208 230/208
Elec. Heating Current (Amps)
12.0/11.1
16.0/14.6 22.9/20.9
12.0/11.1
16.0/14.6 22.9/20.9
Minimum Circuit Ampacity
15 19.9 28.6 15 19.9 28.6
Branch Circuit Fuse (Amps)
15 20 30 15 20 30
LRA - Compressor (Amps)
21.0 21.0 21.0 30.0 30.0 30.0
Cooling Current (Amps)
4.3/4.3 4.3/4.3 4.3/4.3 5.7/5.9 5.7/5.9 5.7/5.9
Basic Heater Size
2.5 kW 3.4 kW 5.0 kW 2.5 kW 3.4 kW 5.0 kW
Power Connection
HARD WIRED HARD WIRED
Recommended Branch
Circuit Wire Sizes
* AWG-American Wire Gauge
14 12 10 14 12 10
VHA 265
MODEL VHA09R VHA12R
Heater Watts
2500 3400 5000 2500 34000 5000
Voltage
265 265
Elec. Heating Current (Amps)
10.5
13.9 19.9 10.5 13.9 19.9
Minimum Circuit Ampacity
13.1 17.4 24.9 13.1 17.4 24.9
Branch Circuit Fuse (Amps)
15 20 30 15 20 30
LRA - Compressor (Amps)
21.0 21.0 21.0 30.0 30.0 30.0
Cooling Current (Amps)
3.5 3.5 3.5 5.1 5.1 5.1
Basic Heater Size
2.5 kW 3.4 kW 5.0 kW 2.5 kW 3.4 kW 5.0 kW
Power Connection
HARD WIRED HARD WIRED
Recommended Branch
Circuit Wire Sizes
* AWG-American Wire Gauge
14 12 10 14 12 10
