Friedrich Wallmaster WCT08A10A - Page 18

18 PB
OPERATION
User Interface
The LIM Menu (LIMIT)
This is the limit menu. See Figure 307.
Upon entering the menu, the rst option will be to set the lower setpoint limit using the arrow buttons. See Figure 308.
Then you can set the higher setpoint limit using the arrow buttons. See Figure 309.
Pressing the menu button completes the limit setting. See Figure 306.
Figure 307
MENU
RETURN
Figure 308
MENU
RETURN
Figure 309
MENU
RETURN
