Friedrich WallMaster WE10B33A User Manual

28
WALLMASTER PARTS
* Not Shown
REF DESCRIPTION PART NO# 115 V 115 V 115 V 230V 230V 230V 230V 230V 230V 230V 230V CODE
CHASSIS PARTS
WS08B10A-B WS10B10A-B WS14B10A-B WS10B30A-B WS13B30B WS16B30A-B WE10B33A-B WE13B33B WE16B33A-B WY10B33A-B WY13B33A-B
16 SHROUD, CONDENSER 62102000 11111111111720
17 FAN BLADE, COND. 62101500 11111111111710
18 BLOWER WHEEL, EVAP. 60610604 11111111111700
19 BLOWER FRONT 62100600 1742
19 BLOWER FRONT 62100601 11 11111111742
20 SCROLL 62102100 11111111111777
25 BASE PAN 62100904 1 730
25 BASE PAN 62100905 11111 730
25 BASE PAN ASLY. 61606209 11111730
26 BELLOWS,DRAIN VALVE 60179903 11111801
27 DRAIN PAN, ASSY. 62101901 11111111111840
* GROMMET, comp. 61028900 33333333333790
* BOLT, comp. 91400400 33333333333791
* COUNTER WEIGHT 61715800 22222222222999
30 RETAINER CUP,FAN MTR 60640600 33333333333999
31 GROMMET,FAN MTR 60640500 33333333333999
32 NUT,FAN MTR 91003000 33333333333999
39 PANEL, CTRL. MOUNT 62100001 11111111111999
41 BRACKET CONRTOL 62100801 11111111111999
43 ESCUTCHEON, COOL 62101106 111111 760
43 ESCUTCHEON, HTG/COOL 62101102 11111760
44 KNOBS, CRTL. 61911600 22222761
* HOLDER, AIR FILTER 60865900 22222222222756
* HOLDER, THERMOSTAT 61900500 11111999
HOLDER, THERMISTER 61925001 111111 999
45 FILTER, AIR 60865811 11111111111754
* FRONT COMPLETE 61607003 11111111111750
46 FRAME HOOD 61612601 11111111111750
47 GRILLE, INTAKE 61612702 11111111111772
48 GRILLE, EXHAUST 61612801 11111111111773
52 DOOR, CTRL. 61613103 11111762
53 END CAP, GRILLE 61613201 11111111111999
WEATHER SEAL GASKET 61578101 11111111111
REF DESCRIPTION PART NO# 115 V 115 V 115 V 230V 230V 230V 230V 230V 230V 230V 230V CODE
CHASSIS PARTS
WS08B10A-B WS10B10A-B WS14B10A-B WS10B30A-B WS13B30B WS16B30A-B WE10B33A-B WE13B33B WE16B33A-B WY10B33A-B WY13B33A-B
* HARDWARE, SCREWS 60846020 11111111111999
* GASKET, CHASSIS 61717301 11111111111780
* CARTON, SHIPPING 61841911 11111111111999
OPTIONAL ACCESSORIES ITEMS
* START KIT 61008903 11111111111160
* SERV.& PART MANUAL WM05 11111111111999
55 SLEEVE (ONLY) 61603601 11111111111770
57 GRILLE, STAMPED 61603001 11111111111771
* FRIEDRICH SCRIPT 61823504 11111111111999
