WM-ServMan (1-11)
WallMaster
®
R-410A Models
2 0 1 1
Service Manual
Cool Only
Cool with Electric Heat
Heat Pump with Electric Heat Back Up
Wa
l
l
M
a
s
t
e
r
Money
Fa
n
Timer Operatio
n
Set Hr
.
Stop
Star
t
Temperatur
e
Fan
Cool
Power
Cooler
War
mer
Only Speed Saver
®
Heat
Air Conditioners and Heat Pumps
Thru-the-wall
*
Last character may vary.
115-Volt: WS08C10
*
, WS10C10
*
, WS12C10
*
230-Volt: WS10C30
*
, WS13C30
*
, WS15C30
*
230-Volt: WE10C33
*
, WE13C33
*
, WE15C33
*
230-Volt: WY09C33
*
, WY12C33
*

Table of Contents

Questions and Answers

  • M
    Matthew CarrollJul 30, 2025
    Why is my Friedrich Air Conditioner not cooling properly and turning on and off frequently?
    • J
      Johnny BrooksJul 30, 2025
      If your Friedrich air conditioner isn't cooling or heating effectively, and cycles on and off too often, consider these possibilities: * Make sure the air vents aren't blocked by things like curtains or furniture. * Check that all windows and doors are properly closed. * Adjust the temperature to a cooler or warmer setting as needed. * Clean any dirt or obstructions from the indoor and outdoor coils. See Routine Maintenance section. * Reduce excessive heat or moisture in the room by using exhaust fans and avoiding heat-producing appliances during hot times. * Give the unit extra time to cool down a very hot room.
  • B
    Brent CookAug 4, 2025
    Why Friedrich air conditioner does not cool or only cools slightly?
    • A
      Adrian WalkerAug 4, 2025
      If your Friedrich air conditioner is not cooling well or only cools slightly, consider the following: * Refer to industry standard sizing chart to check if the unit is undersized. * See alarms and replace thermistor if indoor ambient thermistor is open or shorted. * Clean the filter as recommended in the Owner’s Manual. * Clean dirty or restricted condenser or evaporator coil using pressure wash or biodegradable cleaning agent. * Adjust discharge louvers and use high fan speed to improve air circulation. * Check for leak & make repair if the unit has low capacity undercharge. * Check amperage draw against nameplate and make pressure test if the compressor is not pumping properly.
  • B
    boydchristopherAug 9, 2025
    How to troubleshoot a Friedrich WallMaster WS08C10 that won't turn on?
    • L
      Lisa RichardsonAug 9, 2025
      If your Friedrich air conditioner is not operating, here are some possible causes and solutions: * Ensure the unit is turned on and the temperature is set appropriately. * Check that the LCDI power cord is properly plugged into a grounded outlet. * If the LCDI power cord has tripped (reset button popped out), press the RESET button. * Inspect the circuit breaker or fuse. Reset the breaker or replace the fuse if necessary. If problems continue, contact a qualified electrician. * In case of a local power failure, the unit should resume operation once power is restored.
  • M
    Michael SmithAug 14, 2025
    How to fix a Friedrich WallMaster WS08C10 when the fan motor won't run?
    • D
      Donald HallAug 14, 2025
      If the fan motor in your Friedrich air conditioner isn't running, here are a few things to check: * Test the system button and replace the user interface if it's not working. * Refer to the wiring diagram to check for broken, loose, or incorrect wiring and repair it. * Test the capacitor and replace it if it's inoperative. * Replace the user interface if the fan speed button is defective. * Test the fan motor and replace it if it's inoperative (ensure the internal overload has had time to reset).
  • V
    Veronica Vang DDSAug 19, 2025
    Why does my Friedrich Air Conditioner keep tripping the circuit breaker?
    • B
      Brian WilliamsAug 19, 2025
      If your Friedrich Air Conditioner trips the circuit breaker or blows fuses, it could be due to several reasons: * Other appliances are sharing the same circuit. This unit needs its own dedicated circuit. * An extension cord is in use. Avoid using extension cords with air conditioners. * The circuit breaker, fuse, or wiring isn't properly rated. Ensure you're using components with the correct rating. If issues persist, consult a licensed electrician.
  • G
    garciacynthiaAug 25, 2025
    What to do if the LCDI power cord keeps tripping on my Friedrich Air Conditioner?
    • L
      Lisa RandolphAug 25, 2025
      If your Friedrich Air Conditioner's LCDI power cord trips frequently (reset button pops out), it could be due to disturbances on your power supply line or electrical overload, overheating, or cord pinching. To resolve this, press and release the RESET button. Ensure any underlying issues like electrical overload or cord pinching are addressed before resetting.

Summary

Important Safety Information

Personal Injury or Death Hazards

Details potential dangers to individuals during operation or service.

Electrical Hazards

Outlines risks associated with electrical components and power.

Electrical Data

Plug;Outlet;Circuit Rating

Specifies electrical connection requirements and ratings.

Electronic Control Operation

Testing the Electronic Control

Activating Test Mode

Procedure to enter and use the unit's diagnostic test mode.

Error Code Mode

How to access and interpret stored error codes.

Error Codes Listing for WS Models

Error Codes Listing for WE;WY Models

Components Testing

Fan Motor

Testing procedures for the fan motor.

Refrigeration System Sequence of Operation

R-410 A Sealed System Repair Considerations

R-410 A Sealed Refrigeration System Repairs

Equipment Required

Lists necessary tools and equipment for system repairs.

Equipment Must Be Capable Of

Specifies capabilities required for servicing equipment.

Method Of Charging; Repairs

Hermetic Components Check

Metering Device

Procedures for checking capillary tube metering devices.

Check Valve

Explains the function and testing of the check valve.

Reversing Valve Description;Operation

Checking the Reversing Valve

Procedure For Changing Reversing Valve

Compressor Checks

External Overload

Checking the External Overload

Compressor Replacement

Special Procedure in the Case of Motor Compressor Burnout

Routine Maintenance

Air Filter

Coils and Base Pan

Blower Wheel; Housing; Condenser Fan; Shroud

Electronic; Electrical;Mechanical

General Troubleshooting Tips

Unit Does Not Operate

Unit Trips Circuit Breaker or Blows Fuses

LCDI Power Cord Trips (Reset Button Pops Out)

Unit Does Not Cool;Heat Room Sufficiently, Or Cycles On And Off Too Frequently

Diagnoses for insufficient cooling/heating or frequent cycling.

Cooling Only Room Air Conditioners: Troubleshooting Tips

Compressor Does Not Run

Fan Motor Does Not Run

Does Not Cool or Only Cools Slightly

Solutions for poor cooling performance.

Water leaks into the room

Heat;Cool Only Room Air Conditioners: Troubleshooting Tips

Room temperature uneven (Heating cycle)

Unit Will Not Defrost

Troubleshooting the unit's defrost function.

Does Not Heat Adequately

Diagnosing and fixing insufficient heating performance.

Heat Pump Troubleshooting

Unit Cools When Heat is Called For

Addressing the unit cooling instead of heating.

Heating Insufficient

Troubleshooting inadequate heat pump heating.

Troubleshooting Chart - Cooling

Troubleshooting Chart - Heating (Heat Pump)

Electrical Troubleshooting Chart - Heat Pump

Valve Troubleshooting Touch Test Chart: To Service Reversing Valves

WallMaster Wiring Diagram Electronic Control Cool Only Models

WallMaster Wiring Diagram Electronic Control Cool With Electric Heat Models

WallMaster Wiring Diagram Electronic Control Heat Pump With Electric Heat Models

Installation Instructions for WSD Sleeve

Wall Preparation

Installation Requirements

Sleeve Installation

WallMaster Thru-the-Wall Air Conditioners Limited Warranty

First Year Warranty

Second Through Fifth Year Warranty

Technical Support Contact Information

Friedrich WallMaster WS08C10 Specifications

General IconGeneral
Cooling Capacity8, 000 BTU
Voltage115V
RefrigerantR-410A
Cooling Area350 sq. ft.
Operating Frequency60 Hz
TypeWall-mounted Air Conditioner
