Installation Accessories
45
DK / Drain Kit
Installed at the back of the unit and allow s
for attachm ent to perm anent condensate
disposal system , if disposal is necessary
or desired.
SB / Sub Base
Used as a base for the unit w hen
it is desired to place the cord and
receptacle w ithin the installation, or
sim ply as a base for the unit wh en
m ounted low in the w all.
Necessary wh en installing in a sleeve
deeper than 16 3/4" deep, such as
Fedders B sleeve (19 3/4" deep).
IDK / Internal Drain Kit
New construction applications w here
a condensate drain system has been
built into the w all interior.
1
6
3
/
4
/
/
"
F
e
d
d
e
r
s
B
1
9
3
/
4
/
/
”
IMPORTANT:
Operating the air
conditioner with incorrect
Adapter Kit (on 19 3/4”
deep sleeve) will recirculate
discharge air and cause
compressor overload to trip.
CORRECT Vertical Louvers
INCORRECT Horizontal Louvers
WSC Sleeve
Standard Grille
Exterior Grilles
WSC Sleeve
Optional Architectural Grille- AG
