Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms
against soiled surfaces. Each cycle begins with a pre-drain. Next, the dishwasher fills with water
covering the filter area. Water is then pumped through the filter and spray arms. Soil particles go
down the drain as the water is pumped out and replaced with clean water. The number of water
fills will vary with the cycle being used.
Dishwasher Features
Tub Gasket
page 12
Middle Spray Arm
pages 8,9,14
Top Rack
page 8
Serial Label
(located on right
side of tub)
Bottom Rack
page 9
Lower Spray Arm
pages 9,14
Glass Trap
page 12
Self-Cleaning Filter
page 12
Heating Element
page 12
Overfill Protector
page 12
Vent
pages
4-7,15
Nozzle
Prewash
Detergent Cup
page 10
Detergent Dispenser
page 10
Rinse Aid
Dispenser
page 11
Funnel
pages
8,14
