5DESCRIPTION OF PARTS
General instruction
1. Ice scoop.
2. Ice full sensor
3. Ice basket
4. Top cover with transparent window
5. Air exhausting
6. Water drain cap: at front btm side of the unit.
7. MAXIMUM WATER LEVEL:
▲
Remove the ice basket, you can see the water level mark.
Position of control panel & function
Control Panel: Easy to use, visible functions touch display setting.
A. Selected ice size displaying: Small and Large.
B. Power indicator
C. Ice Full indicator
D .Water shortage indicator
E. Button to turn on/o the unit.
F. Button to select ice cube size.
.
D C
E F
B A
